CEMUX Inner Drawer System 199mm High with FROSTED GLASS

Price range: $5.50 through $6.50 (ex GST)

  1. Order below items separately for 199mm High Inner Drawer – WHITE
  2. CEMXU 84mm High drawer 11.A3201 (Sizes available: 270mm – 550mm)
  3. Back Bracket 199mm L/R – WHITE
  4. Front Section 1200mm – WHITE
  5. Cross Square Rail 1200mm – WHITE
  6. Front Inner Drawer Bracket L/R 199mm – WHITE
  7. 199mm High Frosted Glass L/R
  8. 199mm High Glass Fastener L/R
Clear
SKU: N/A Category:
  • FEATURES
    1. Perfect sliding qualities with precision full extension runners incorporating silent & gradual closing
    2. Colour – White
    3. Quick installation and easy dismantling
    4. +/- 2mm up & down adjustment
    5. +/- 1.5mm left & right adjustment
    6. Integrated 3D front panel adjustment
    7. 40Kg dynamic loading capacity and 100,000 cycles tested.



CODE DESCRIPTION PKG
Order below items for 199mm High Inner Drawer with FROSTED GLASS
11.A3201.(*) Choose Soft Close Drawer System 270mm – 550mm White 1 Set
11.AL321200W Front Section 1200mm for Inner Drawer WHITE 1 Pc
11.HF321200W Cross Square Rail 1200mm WHITE 1 Pc
11.AF320401W Front Brackets for Inner Drawer to suit 199mm drawer 1 PAIR
11.AR3204183W Back Bracket to suit 199mm drawer – WHITE 1 PAIR
11.AB1838(*) 8mm Frosted Glass 199mm H (Size 400mm, 450mm or 500mm) 1 PAIR
11.AB1838W Glass Holder / fastener 199mm L/R 1 PAIR
