CEMUX Inner Drawer System 167mm High with FROSTED GLASS

$5.50 – $6.50 (ex GST)

  1. Order below items separately for 167mm High Inner Drawer – WHITE
  2. CEMXU 84mm High drawer 11.A3201 (Sizes available: 270mm – 550mm)
  3. Back Bracket 167mm L/R – WHITE
  4. Front Section 1200mm – WHITE
  5. Cross Square Rail 1200mm – WHITE
  6. Front Inner Drawer Bracket L/R 167mm – WHITE
  7. 167mm High Frosted Glass L/R
  8. 167mm High Glass Fastener L/R
Clear
SKU: N/A Category:
  • FEATURES
    1. Perfect sliding qualities with precision full extension runners incorporating silent & gradual closing
    2. Colour – White
    3. Quick installation and easy dismantling
    4. +/- 2mm up & down adjustment
    5. +/- 1.5mm left & right adjustment
    6. Integrated 3D front panel adjustment
    7. 40Kg dynamic loading capacity and 100,000 cycles tested.
CODEDESCRIPTIONPKG
Order below items for 167mm Inner Drawer with FROSTED GLASS
11.A3201.(*)Choose Soft Close Drawer System 270mm – 550mm White1 Set
11.AL321200WFront Section 1200mm for Inner Drawer WHITE1 Pc
11.HF321200WCross Square Rail 1200mm WHITE1 Pc
11.AF320301WFront Bracket for Inner Drawer to suit 167mm drawer1 PAIR
11.AR3203151WBack Bracket to suit 167mm drawer – WHITE1 PAIR
11.AB151(*)8mm Frosted Glass 167mm H (Size 400mm, 450mm or 500mm)1 PAIR
11.AB1518WGlass Holder / fastener 167mm L/R1 PAIR
