Technical specifications:
- Depth of the metal cup 11.3mm
- Cup diameter 35mm
- Opening 105° with (K) max 4mm and (T) max 18mm
- Possibility of door drilling (K) from 3 to 7 mm
- Thickness of the door (T) from 16 to 26 mm
| CODE | DESCRIPTION | DRILLING | CUP DIA / DEPTH |
|---|---|---|---|
| 7.V17A107S | CEMUX IMPRESSO – 105° Soft Close Hinge – TOOLESS, Crank 0, 45mm hole distance | 45 | 35 / 11.3 |
All dimensions are in mm
